Perception Lighting Apex 180° Ultra Wide LED Driving Lights (Pair)
In Stock - Ready for immediate dispatch or pickup
Pickup Available from Punchbowl, NSW
BLACK FRIDAY SALE!
Ends in:Buy Now, Pay Later.
DETAILS
Overview
See the whole track, not just the road ahead
The Apex 180 is a pair of 215 mm round LED driving lights built for width. 41 Osram LEDs per light, a hyper wide reflector and built-in side shooter LEDs spread light across 180°, lighting up the verges, the trees and the next bend, while still reaching 874 m to 1 lux.
It suits tight bush tracks, farm roads, mine sites and anywhere you need to see what is coming from the side.
Panoptic beam
180° of light
Most driving lights throw a narrow pencil of light down the road. The Apex 180 does the opposite: the hyper wide reflector and built-in side shooter LEDs push light out to both sides, so the edges of the track are as clear as the middle.
- ✓Wide: see wildlife stepping out from the scrub before it reaches the road
- ✓Still reaches: 874 m to 1 lux, 1,748 m to 0.25 lux
- ✓Colour: 5700K daylight white for less eye strain
Built for the long haul
Sealed, quiet and tough
IP69K is the highest dust and water rating there is: the Apex 180 is dust tight, waterproof to 3 m and safe to clean with a high-pressure, high-temperature wash. A Gore breather stops condensation, and CISPR Class 3 certification means no hiss on your UHF or radio.
- ✓Lens: GE Lexan polycarbonate that will not crack or shatter
- ✓Finish: Dupont powdercoat so the colour won’t fade
- ✓Power: 9-32 V DC input suits 12 V and 24 V vehicles
Mounting
Solid three-point mount
Each light sits on a 5.5 mm 304 stainless steel bracket with a three-point mount, so it holds its aim on rough roads. Torx anti-theft security bolts make them harder to pinch, and Deutsch plugs and stainless hardware are in the box.
Size: 215 mm across and 245 mm tall including the bracket. Bracket base 70 mm deep with 95 mm bolt spacing.
Beam pattern
Wide and still long
The lux diagram shows the Apex 180 spreading light wide close to the vehicle while still reaching 874 m to 1 lux. Pair it with long-range spot lights such as the Apex 8.5" if you want both width and distance.
Frequently asked questions
Is the Apex 180 sold as a pair?
Yes. You get two lights, two brackets, Deutsch plugs and the mounting hardware.
How is it different from the Apex 7" and 8.5"?
The Apex 7" and 8.5" use a spot reflector for maximum distance. The Apex 180 trades some reach for a much wider beam that lights up the sides of the track.
Will they run on 24 V?
Yes. The 9-32 V DC input suits 12 V and 24 V vehicles, including trucks.
Will it interfere with my UHF?
No. It is CISPR Class 3 certified for low radio interference.
Do I need a wiring harness?
Yes, a driving light harness with a relay and switch is needed and is sold separately. If you are unsure what suits your vehicle, please contact our team.
Which Apex should I choose?
For the longest reach, the round Apex 7" and 8.5" use a spot reflector. For the widest light on tight tracks, the Apex 180 spreads its beam across 180°. For a compact square light with daytime running lights, choose the Apex Quad. Also in the range: the Apex 7" (185 mm, 1,480 m), the Apex 8.5" (220 mm, 1,786 m) and the Apex Quad (188 x 151 mm, DRL built in).
What warranty do they have?
10 years, backed by Perception Lighting in Australia. If you ever have a problem, please contact our team.
Do you supply fleet or bulk orders?
Yes. Please contact our team for a quote.
Features
- ✓22,000 lumens per pair (11,000 per light)
- ✓180° beam spread for full peripheral vision
- ✓1 lux at 874 m and 0.25 lux at 1,748 m
- ✓Hyper wide reflector plus built-in side shooter LEDs
- ✓41 genuine Osram high-output LEDs per light, 5700K
- ✓Multi-volt 9-32 V DC input for cars and trucks
- ✓IP69K: dust tight and high-pressure waterproof to 3 m
- ✓CISPR Class 3 certified for no radio or UHF interference
- ✓Torx anti-theft security bolts on stainless brackets
- ✓Gore breather, Dupont powdercoat and Deutsch plugs
Product Details
| SKU | APEX-180 |
| Barcode # | 9359968000104 |
| Brand | Perception Lighting |
| Type | Lightbars |
| Type | Driving Lights |
| SKU | APEX-180 |
| Shipping Weight | 7.7800kg |
| Shipping Width | 0.390m |
| Shipping Height | 0.140m |
| Shipping Length | 0.570m |
| Shipping Cubic | 0.031122000m3 |
Perception Lighting is an automotive lighting and wiring specialist for the 4WD, caravan and camping industry, known for vehicle-specific solutions that are hard to find anywhere else. Perception Lighting has spent more than a decade focused on one thing: lighting and wiring that work properly on Au...
